Mini PC Q31100GT 1U18 Series

Mini PC Q31100GT 1U18 Series

Q31100GT-1U18 1U rackmount industrial PC powered by Intel 11th Gen Tiger Lake processor, featuring 10× Intel I226-V 2.5G LAN, HDMI and DisplayPort, triple M.2, SATA storage and RS-232, with Windows 11 and Linux support.

Total of Network Interfaces
10
SFP(+)
0
10G RJ45
0
2.5G RJ45
10
1G RJ45
0
Serial Ports
1
Send Inquiry Explore specifications

Tell us the configuration and quantity you need.

Overview

Main Features

  • Intel 11thTiger Lake Processor

  • 1 × Display Port, 1 × HDMI

  • 2 × USB 3.0

  • 2 × M.2, 1 × SATA 3.0

  • 1 × RS-232 (RJ-45)

  • 10 × Intel I226-V 2.5 Gigabit LAN

Specifications


Processor System
CPUntel 11th Tiger Lake Processor
CPU TDPBy CPU
Memory2 × DDR4 SO-DIMM Socket (Up to 64G, 2133/2400MHz)
ChipsetBy CPU
GraphicsBy CPU
LAN Chipset10 × Intel I226-V 2.5 Gigabit LAN
Watch DogYes
Front I/O
Power Button1 × Power Button, 1 × CMOS Clear Button
LED1 × Power LED, 1 × HDD LED
Rear I/O
Power1 × DC Jack
USB2 × USB 3.0
Video Output1 × Display Port, 1 × HDMI
LAN10 × Intel I226-V 2.5 Gigabit LAN
Storage
Type1 × 2.5-inch HDD/SSD
1 × M.2 for SSD (M key, Type: 2280, PCIe 4.0 × 4)
1 × M.2 for SSD (M key, Type: 2280, PCIe 3.0 × 1)
Expansion
M.21 × M.2 for SSD
(M key, Type: 2280, PCIe 4.0 × 4)
1 × M.2 for SSD
(M key, Type: 2280, PCIe 3.0 × 1)
1 × M.2 for Wi-Fi (E key, Type: 2230)
1 × M.2 for 4G/5G (B key, Type: 3042/3052)
SIM Card Slot1
AutoStart JumperYes, 1 × 3Pin, Pitch 2.0mm
CMOS Clear JumperYes, 1 × 3Pin, Pitch 2.0mm
GPIO1, 2 × 5Pin, Pitch 2.0mm
Power Requirement
Power Adapter12V7A
DC Jack5.5mm, 2.5mm
Environmental
Operating Temp0°C~50°C
Non-Operating Temp-20°C~80°C
Humidity10%~90%
Mechanical
MaterialAluminium Alloy
Dimension440 × 124 × 44mm
Weight1.5kg
MountingNo
Packaging Dimension545 × 180 × 90mm
Kensington LockNo
Cooling ModeFan
OS Support
OSUEFI Windows 10, UEFI Linux

In the box

Packing List

NO.CategoryQuantityRemark
1Mini PC1
2AC Power Cord1
3Screws for SATA SSD/HDD1
4SATA cable for SSD/HDD1Option
5Antennas2Option
ItemQuantity
  • 1
    Mini PC
    1
  • 2
    AC Power Cord
    1
  • 3
    Screws for SATA SSD/HDD
    1
  • 4
    SATA cable for SSD/HDD
    Option
    1
  • 5
    Antennas
    Option
    2

Models & options

Ordering and Specifications Information

Quick Order Model: Q31100GT-1U18

Ordering CodeCaseCode Name Processor TypeProcessor Number# of Cores# of ThreadsBase FrequencyMax Turbo Frequency CacheProcessor GraphicsTDP
Q31111GT1U18Tiger LakeCeleron6305221.8GHz/4MIntel UHD Graphics15W
Q31121GT1U18Tiger LakePentium7505242.0GHz3.5GHz4MIntel UHD Graphics15W
Q31131GT1U18Tiger LakeCore i31115G4243.0GHz4.1GHz6MIntel UHD Graphics12-28W
Q31132GT1U18Tiger LakeCore i31125G4482.0GHz3.7GHz8MIntel UHD Graphics12-28W
Q31151GT1U18Tiger LakeCore i51135G7482.4GHz4.2GHz8MIntel Iris Xe Graphics12-28W
Q31152GT1U18Tiger LakeCore i51145G7482.6GHz4.4GHz8MIntel Iris Xe Graphics12-28W
Q31153GT1U18Tiger LakeCore i51155G7482.5GHz4.5GHz8MIntel Iris Xe Graphics eligible12-28W
Q31171GT1U18Tiger LakeCore i71165G7482.8GHz4.7GHz12MIntel Iris Xe Graphics12-28W
Q31172GT1U18Tiger LakeCore i71185G7483.0GHz4.8GHz12MIntel Iris Xe Graphics12-28W
Q31173GT1U18Tiger LakeCore i71195G7482.9GHz5.0GHz12MIntel Iris Xe Graphics eligible12-28W
Q51151GT1U18Tiger LakeCore i511300H482.6GHz4.4GHz8MIntel Iris Xe Graphics28-35W
Q51152GT1U18Tiger LakeCore i511320H482.5GHz4.5GHz8MIntel Iris Xe Graphics eligible28-35W
Q51171GT1U18Tiger LakeCore i711370H483.0GHz4.8GHz12MIntel Iris Xe Graphics28-35W
Q51172GT1U18Tiger LakeCore i711375H483.0GHz5.0GHz12MIntel Iris Xe Graphics28-35W
Q51173GT1U18Tiger LakeCore i711390H482.9GHz5.0GHz12MIntel Iris Xe Graphics eligible28-35W
Q31111GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Celeron
Processor Number
6305
# of Cores
2
# of Threads
2
Base Frequency
1.8GHz
Max Turbo Frequency
/
Cache
4M
Processor Graphics
Intel UHD Graphics
TDP
15W
Q31121GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Pentium
Processor Number
7505
# of Cores
2
# of Threads
4
Base Frequency
2.0GHz
Max Turbo Frequency
3.5GHz
Cache
4M
Processor Graphics
Intel UHD Graphics
TDP
15W
Q31131GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i3
Processor Number
1115G4
# of Cores
2
# of Threads
4
Base Frequency
3.0GHz
Max Turbo Frequency
4.1GHz
Cache
6M
Processor Graphics
Intel UHD Graphics
TDP
12-28W
Q31132GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i3
Processor Number
1125G4
# of Cores
4
# of Threads
8
Base Frequency
2.0GHz
Max Turbo Frequency
3.7GHz
Cache
8M
Processor Graphics
Intel UHD Graphics
TDP
12-28W
Q31151GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i5
Processor Number
1135G7
# of Cores
4
# of Threads
8
Base Frequency
2.4GHz
Max Turbo Frequency
4.2GHz
Cache
8M
Processor Graphics
Intel Iris Xe Graphics
TDP
12-28W
Q31152GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i5
Processor Number
1145G7
# of Cores
4
# of Threads
8
Base Frequency
2.6GHz
Max Turbo Frequency
4.4GHz
Cache
8M
Processor Graphics
Intel Iris Xe Graphics
TDP
12-28W
Q31153GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i5
Processor Number
1155G7
# of Cores
4
# of Threads
8
Base Frequency
2.5GHz
Max Turbo Frequency
4.5GHz
Cache
8M
Processor Graphics
Intel Iris Xe Graphics eligible
TDP
12-28W
Q31171GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i7
Processor Number
1165G7
# of Cores
4
# of Threads
8
Base Frequency
2.8GHz
Max Turbo Frequency
4.7GHz
Cache
12M
Processor Graphics
Intel Iris Xe Graphics
TDP
12-28W
Q31172GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i7
Processor Number
1185G7
# of Cores
4
# of Threads
8
Base Frequency
3.0GHz
Max Turbo Frequency
4.8GHz
Cache
12M
Processor Graphics
Intel Iris Xe Graphics
TDP
12-28W
Q31173GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i7
Processor Number
1195G7
# of Cores
4
# of Threads
8
Base Frequency
2.9GHz
Max Turbo Frequency
5.0GHz
Cache
12M
Processor Graphics
Intel Iris Xe Graphics eligible
TDP
12-28W
Q51151GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i5
Processor Number
11300H
# of Cores
4
# of Threads
8
Base Frequency
2.6GHz
Max Turbo Frequency
4.4GHz
Cache
8M
Processor Graphics
Intel Iris Xe Graphics
TDP
28-35W
Q51152GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i5
Processor Number
11320H
# of Cores
4
# of Threads
8
Base Frequency
2.5GHz
Max Turbo Frequency
4.5GHz
Cache
8M
Processor Graphics
Intel Iris Xe Graphics eligible
TDP
28-35W
Q51171GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i7
Processor Number
11370H
# of Cores
4
# of Threads
8
Base Frequency
3.0GHz
Max Turbo Frequency
4.8GHz
Cache
12M
Processor Graphics
Intel Iris Xe Graphics
TDP
28-35W
Q51172GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i7
Processor Number
11375H
# of Cores
4
# of Threads
8
Base Frequency
3.0GHz
Max Turbo Frequency
5.0GHz
Cache
12M
Processor Graphics
Intel Iris Xe Graphics
TDP
28-35W
Q51173GT1U18
Case
1U18
Code Name
Tiger Lake
Processor Type
Core i7
Processor Number
11390H
# of Cores
4
# of Threads
8
Base Frequency
2.9GHz
Max Turbo Frequency
5.0GHz
Cache
12M
Processor Graphics
Intel Iris Xe Graphics eligible
TDP
28-35W
